Teledyne MEC Traveling Wave Tubes provide the source for RF energy in many commercial test and measurement applications, such as evaluating the electromagnetic susceptibility of components in military systems or consumer/commercial products.

DATASHEETS

TMS TWT Product Selection Guide

PROVEN PERFORMANCE AT-A-GLANCE

Large selection of catalog CW and Pulse TWTs for narrow and wide band operation available, as well as customization of existing TWTs. Examples of frequency band/power combinations:

Band	Frequency	CW Power	Pulse Power (Peak)
L/S-Bands	1 to 4 GHz	500W	10kW+
C-Band	4 to 8 GHz	630W	4.5kW+
X-Band	8 to 12 GHz	425W	10kW
Ku-Band	12 to 18 GHz	425W	4kW+
K/Ka-Bands	18-40 GHz	50W	400W

APPLICATIONS

Electromagnetic Compatibility/Interference/Susceptibility
Threat Simulators (e.g., radar cross-section measurement)
High Power Component Testing
