Capabilities

​



Manufacturing

Teledyne MEC manufacturing complex encompasses over 160,000 square feet of space, with 8,500 square feet of that dedicated to our clean manufacturing facility. This facility is a fully-outfitted space equivalent to a Class 10,000 Clean Room. In addition, our manufacturing capabilities include a full in-house Machine Shop, on-site Chemical and Analytical Lab, and expert-staffed Environmental Test, Inspection, and Calibration departments.

With our veteran staff of engineers, machinists, chemists, technicians, and assemblers, and our comprehensive suite of vigorously-maintained equipment, Teledyne MEC is able to quickly assess the needs of a particular project and put into place a timely and successful product plan, from prototyping all the way through to full production.

Facilities

  • 160,000 total sq. ft. of manufacturing floor space
  • 8,500 sq. ft. of clean manufacturing space--equivalent to a class 10,000 Clean Room
  • Utilities: 120/240V Single Phase, Nitrogen gas, liquid Nitrogen, Hydrogen, water (cooling)

Equipment

  • Over 200 unique RF-High Power Test & Aging Stations
  • Laser Welders
  • TIG Welding
  • Bell Jar Brazing
  • Leak Checkers
  • Optical Comparator
  • H2 Furnaces up to 1350° C
  • Air furnaces up to 1350° C
  • High Vacuum Furnaces up to 1650° C
  • MRC 903-Style Sputter Units
  • XRF
  • Over 30 Turbo Pump Exhaust Stations

Machine Shop

MEC features a full-capability in-house machine shop staffed with a team of experienced machinists and outfitted with an impressive complement of equipment. Maintained to strict standards, this equipment is capable of holding to the tightest of tolerances. Our machinists, meanwhile, set us apart with their intimate knowledge of our products and processes. This familiarity and experience allows these craftsmen to create tooling and components in real-time, turning a design into a usable prototype often in a single day.

Equipment

  • Several Fully Automatic CNC Milling Centers including a VF-3 HASS (40" travel in the X direction)
  • Bridgeport Mill (numerically controlled)
  • Hardinge Wide-Bed Lathe


Personnel


Over 150 years of combined Machine Shop personnel experience

Model / Tool & Die Shop – Prototyping & Production
Equipment

6 Bridgeport Mills (numerically controlled)

Hardinge Wide-Bed Lathes

Turn Master Lathe capable of turning 15" dia material

Shear

Brake

ID/OD Grinder

66 Ton Presses

Brown & Sharp Surface Grinder

Personnel

Over 200 years of combined Machine Shop experience

Chemical and Analytical Lab

A critical part of MECs manufacturing success is our complete in-house Chemical and Analytical Lab. The precision processes required in the development and manufacture of TWTs—such as plating, anodizing, and electro-polishing, as well as material analysis—can all be undertaken at our facility under the control and supervision of our expert chemists, technicians and engineers. This on-site presence allows us to react quickly to manufacturing requirements and to refine processes within rigorous schedules.

  • Dull Ni Plating
  • Electroless Ni Plating
  • Copper Sulfate Plating
  • Gold Plating
  • Ni/Cu ID Plating line
  • XRF
  • Anodizing Clear/Black
  • Chemical Cleaning & Electro-Polishing
  • AAS
  • C/S Analyzer
  • Volumetric Analysis
